Hydraulic Inbuilt Puller

Model Number Capacity (Ton) Stroke A (mm) Reach (mm) Spread (mm) Tip Weight (Kg) B C D CK-4 4 60 185 255 42 22 84 6.7 Ck-6 6 70 220 330 45 23 94 7.4 CK-8 8 85 230 350 50 25 122 8.2 CK-10 10 85 270 375 60 28 118 10.5 CK-12 12…

Description

CK SERIES
FEATURES:
  • Comes with 2/3 jaws combination puller head..
  • Broad capacity range of 4,6,8, and 15 tons
  • Integrated safety valve for overload protection..
  • Spring loaded hydraulic cylinder rod.
  • Removable and 3600 rotary pump handle.
  • High quality, heat treated forged allow steel components provide superior reliability and service.
  • Have been vigorously tested for top performance and perfection.
  • Light weight and compact design.
  • Comes with fast adjusting nut for rapid adjustment.
  • Supplied with sturdy storage case.
  • The perfect shape and structure for puller jaws.
  • Comes with 2/3 jaws combination puller head.
  • Broad capacity range of 10,12,20,25 and 30 tons.
  • Integrated safety valve for overload protection.
  • High quality, heat treated forged alloy steel components provide superior reliability and service.
  • Extra long jaws for added capability of pulling a wider variety of parts (some models only)
  • Available with or without full hydraulic set.
